HONDA OF LAFAYETTE — PARTS ARCHIVE READER v2.1 POSITION: 000

FILM 001 — ATC250R // 1985 FRAME & SUSPENSION

F-01FRAME ASSEMBLY, MAIN61100-KA4-000
F-02FRAME, SUB (REAR)61200-KA4-000
F-03GUARD, FRAME (L)50610-KA4-000
F-04GUARD, FRAME (R)50620-KA4-000
F-05SHOCK ABSORBER ASSY (REAR)52400-KA4-831
F-06SPRING, REAR SHOCK (RED)52401-KA4-831
F-07FORK SET, FRONT (L&R)51400-KA4-831
F-08SEAL SET, DUST (FORK)51490-KA4-000
F-09LINK, SWINGARM52200-KA4-010
F-10BEARING, SWINGARM PIVOT91001-KA4-003

FILM 002 — ATC250R // 1985 ENGINE TOP END

E-01CYLINDER ASSY12100-KA4-831
E-02PISTON (STD)13101-KA4-831
E-03RING SET, PISTON (STD)13010-KA4-831
E-04HEAD, CYLINDER12200-KA4-831
E-05GASKET, CYLINDER HEAD12251-KA4-000
E-06REED VALVE ASSY14100-KA4-000
E-07POWERVALVE ASSY18320-KA4-831
E-08GOVERNOR, EXHAUST VALVE18390-KA4-000
E-09GASKET, EXHAUST (2)18291-KA4-000
E-10PLUG, SPARK (CR8EH-9)98079-58916
NOTE:
E-07 backorder
since 3/12.
check Cali.
— Terry

FILM 003 — CR250R // 1987 CARB & FUEL

C-01CARBURETOR ASSY (PE38)16100-KS7-831
C-02JET, MAIN (#175)99101-357-1750
C-03JET, SLOW (#42)99103-357-0420
C-04NEEDLE, JET (N80F)16172-KS7-831
C-05CLIP, NEEDLE (3RD GROOVE)16178-KS7-000
C-06FLOAT ASSY16013-KS7-000
C-07GASKET SET, CARB16010-KS7-305
C-08FUEL TANK (3.1 GAL)17510-KS7-000
C-09PETCOCK ASSY16950-KS7-000
C-10FILTER, FUEL (INLINE)16900-KS7-003

FILM 004 — GL1100 GOLDWING // 1982 ELECTRICAL

L-01CDI UNIT ASSY30400-MF0-010
L-02COIL, IGNITION (L)30501-MF0-010
L-03COIL, IGNITION (R)30502-MF0-010
L-04REGULATOR, VOLTAGE31600-MF0-010
L-05STATOR ASSY31120-MF0-010
L-06BATTERY (12V 18AH)31500-MF0-010
L-07FUSE (15A) (3)98200-31500
L-08SWITCH ASSY, STARTER35100-MF0-010
L-09HORN (12V)38100-MF0-010
L-10RELAY, TURN SIGNAL38300-MF0-010
L-04 and L-05
always fail
together.
order both.
trust me.
— D.B.
◂ drag to slide film sheet ▸

▸ ARCHIVE SHELF

FILM 001 ATC250R — Frame & Suspension (1985) [LOADED]
FILM 002 ATC250R — Engine Top End (1985) [LOADED]
FILM 003 CR250R — Carb & Fuel System (1987) [LOADED]
FILM 004 GL1100 Goldwing — Electrical (1982) [LOADED]
FILM 005 TRX250R — Transmission (1988) // scanning //
FILM 006 XR600R — Valve Clearance Spec Card (1989) // scanning //
